3G/HD/SD-SDI to HDMI Converter

$899.00USD

Model:
C-3GHDSDI-HDM
Shipping Weight:
3.5lbs

Overview

The Avenview C-3GHDSDI-HDM provides a cost effective way to convert 3G/HD/SD-SDI signal to HDMI compliant format. The conversion between SDI and HDMI is pure digital and guarantees no loss transformation for both audio and video. Plus, with up to 8 channels audio support, 7.1 channel or 5.1 channel audio becomes available.

The C-3GHDSDI-HDM also provides 2 low jitter and re-clocked outputs for daisy chain or multiple monitors.

HDMI Extender over CAT5 Application Diagram

Features

  • Supported 3G formats(SMPTE 425M, Level A):
    • 1080p @50/59.94/60Hz (4:2:2)
  • Supported high-definition (HD) formats:
    • 1080i @50/59.94/60Hz, 1035i @50/59.94/60Hz, 720p @50/59.94/60Hz
  • Supported standard-definition (SD) formats: NTSC @59.94Hz, PAL @50Hz
  • Auto 3G/HD/SD-SDI detection
  • Two equalized and re-clocked loop outputs
  • External DIP Switch Configuration

Technical Specifications

ModelC-3GHDSDI-HDM
Description3G/HD/SD-SDI to HDMI Converter
SDI Standards3G-SDI, HD-SDI, SD-SDI
Auto 3G/HD/SD DetectionYes
Video Bandwidth2.97 Gbps, 2.970/1.001 Gbps
Video Support3G: 1080p @50/59.94/60Hz (4:2:2)
HD: 720p @50/59.94/60Hz, 1035i @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @24/30Hz
SD: NTSC @59.94Hz, PAL @50Hz
Input Signal3G-SDI: SMPTE 424M/425M
HD-SDI: SMPTE 292M, 296M
SD-SDI: SMPTE 259M
Output SignalHDMI
Audio Mode7.1 / 5.1 / Stereo
Eye Pattern CharacteristicsExtra Low Alignment jitter 0.05UI at HD
Cable Equalization3G-SDI: up to 60m (200ft)
HD-SDI: up to 150m (500ft)
SD-SDI: up to 300m (1000ft)
Loop Out2 equalized and reclocked SDI loop outs
Audio SupportYes
Input1 x BNC (SDI)
Output1 x HDMI
2 x BNC (SDI)
BNC Connector3G 75Ω inter-locked socket
HDMI ConnectorType A (19 pin female)
Power Supply5V 4A DC
Power Consumption3 Watt (max)
Operating Temperature0~40C (32~104F)
Storage Temperature-20~60C (-4~140F)
Relative Humidity20 ~ 90% RH (no condensation)

Package Contents

  • 1 x C-3GHDSDI-HDM
  • 1 x Power Adapter
  • 1 x User’s Manual

User Guides

Avenview 3G/HD/SD-SDI to HDMI Converter User GuideAvenview 3G/HD/SD-SDI to HDMI Converter User Guide
