8 Port VGA / Component Switch with Audio

Overview

Avenview VGA-VS-8X1, 8 Port VGA/Component Switch with Audio receives and amplifies up to 8 VGA or component inputs, perfectly switches the desired input to the VGA/component equipped monitor or receiver.

The switch supports VGA or component video up to 350MHz. The re-transmitted video quality is guaranteed and the longest transmission is up to 65m (210ft). Therefore, VGA-VS-8X1 offers the most convenient and cost effective means for swift switch of high quality PC graphics and HDTV videos with crystal clear audio in the market.

With equipped audio switch, VGA-VS-8X1 is ready to be as a switch with stereo audio and ideally for boardroom, showroom, and exhibition. The control of VGA-VS-8X1 is versatile and easier through the IR remote control, the push button on front panel, or the RS-232 control on rear panel.

Features

• VGA/component switch with 350MHz bandwidth
• Up to 8 graphics/video inputs
• LED indication
• Automatic detection of the VGA/component input
• Amplified video output with transmission length up to 65m (210ft)
• Multiple control by IR remote, push button, and RS-232 control

Technical Specifications

Package Contents

User Guides
