Overview

The Avenview DVI-VIDEOWALL-9X, 9-Display Video Wall Processor is a powerful, most cost effective, and fully real time data/video processor for multiple flat panel displays or projectors. Thru DVI transmission, the quality of the outcome videos is guaranteed. The output display is grained up to 255 by 255 squares. Virtually any setups for the display layout can be possible by the provided software. The DVI-VIDEOWALL-9X allows you to manipulate two input videos, wherever positions and whatever sizes you want for viewing. The embedded scalar converts signals from two of the input sources to match the native resolution of monitors, flat panel displays, projectors as well as user-selectable output settings up to WUXGA (1920x1200). The DVI-VIDEOWALL-9X sends the resulting mixed video thru DVI interface to the connected monitors/projectors based on the display layout. The layout can be readily modified to fit your applications and optimize visual effects. Typical applications include digital signage, and broadcasting/education/surveillance systems etc.

Features

• Nine DVI outputs from 640x480 to 1920x1200 with a local loop out for monitoring
• Supports HDMI, DVI, S-Video, CVBS, Component, and VGA input, from 640x480 to 1920x1200, interlaced or progressive
• Advanced video de-interlace for improving 480i and 576i SD video input
• PIP, PAB, Full screen modes and adjustable size& position through software
• Resize, position, flip, zoom output video
• Perfectly as a video screen splitter, a video converter and a video switcher
• Each DVI output has an independent controllable display area
• User-selectable output settings, up to 1920x1200
• Can be cascaded to obtain more displays
• Image parameters and layouts are automatically saved in flash memory of the device and can be recalled for later use
• Several Image parameters and layouts can be saved in computers and can be loaded for later use
• Software control through RS-232/RS-485
• Built-in long distance RS-232 control port over Cat-5e
• Firmware upgradable for support of new features and technology enhancements
• Built-in factory reset switch
• 2U size
