Component to VGA Converter / Switch with Audio

$145.00USD

  • Model: C-COMP-VGA
  • Shipping Weight: 3lbs


Quantity:


Overview

Avenview C-COMP-VGA Component to VGA Converter with Audio receives and switches two video and stereo audio sources and displays one of them on a VGA monitor, plasma TV, LCD or a projector in high resolution formats. The C-COMP-VGA accepts both VGA and Component inputs, and converts Component inputs to VGA outputs. With only a press of a button, you can select between your PC and game console, such as PS2, PS3, Wii, XBOX, XBOX3 and DVD Player.

HDMI Extender over CAT5 Application Diagram

Features

  • Automatic conversation between Component and VGA
  • Supports PC video display resolutions of up to UXGA (1600x1200 @ 75Hz)
  • Component supports 480p, 576p, and 720p
  • Buffered VGA output for 60m (200 feet) long range transmission
  • Stereo audio switch

Technical Specification

Description Component to VGA Converter / Switch
Video Bandwidth 400MHz for VGA
70MHz for Component
Input Connectors 1 x VGA
1 x Component
2 x Stereo Audio
Output Connectors 1 x VGA
1 x Audio Out
Power Supply 5VDC, 1Amp Adapter
Dimension (L x W x H) 5" x 3.7" x 1"

Package Contents

  • 1 x C-COMP-VGA
  • 1 x Power Adapter
  • 1 x User’s Manual

User Guides

Avenview 3G/HD/SD-SDI to HDMI Converter User GuideC-COMP-VGA User Guide
