Description

Overview

Avenview C-HDM-EXD-A HDMI Audio Extractor allows extraction of audio signals from any HDMI source. The original, unaltered HDMI audio/video signal is sent to display as normal unedited format, while the audio outputs can be connected to your home theater audio system for a superior audio experience.

With C-HDM-EXD-A Audio Extractor you can carry the source HDMI audio signal and convert it to digital optical or analog Stereo (L/R) audio. All digital audio formats (including 5.1/7.1 SURROUND) may easily be converted to analog L/R stereo RCA by setting the audio output switch to 2CH-LPCM.

The HDMI output must be connected to a display for the converter to extract the audio signal.

Features

Compliant with HDMI, HDCP 1.2 and DVI 1.0
Supports HDMI audio sampling rates up to 192 kHz
Supports Optical S/PDIF sampling rates up to 48 kHz
Supports TMDS clock frequency rate 225 MHz
Supports high-bit-rate (HBR) audio
No HDMI output connection is required to receive audio at the analog and optical outputs
Maximum input and output HDMI cable length can run up to 15 meters at 1080p at 8-bit resolution
Low power consumption
Supports EDID management for audio formats, can switch among built-in EDID (LPCM 2CH/Bitstream) and external EDID (TV)

Technical Specifications

ITEM	DESCRIPTION
UNIT	C-HDM-EXD-A
UNIT DESCRIPTION	HDMI Audio Extractor
INSTALLATION	No installation needed
HDMI Audio Sampling Rate	Up to 192 kHz
Optical Audio Sampling Rate	Up to 48 kHz
HDMI Audio Format	LPCM 2/5.1/7.1CH, Dolby 5.1, DTS 5.1,DD+,D-TrueHD & DTS-HD
Optical Audio Format	LPCM 2CH, Dolby 5.1 & DTS 5.1
Input	1 x HDMI (Supports DVI to HDMI cable or DVI adapter)
Output	1×HDMI, 1×Optical,1×L/R
Power Consumption	2.1 W
Power Supply	5 V/1 A linear power adaptor (US/EU Standards
Dimensions (L x W x H)	3.57′ (W) × 3.38′ (D) × 1.34 (H)
Weight	0.24 lb
Power Consumption	2.1W
Operating Temperature	0 °C~40 °C/32 °F~104 °F
Storage Temperature	-20 °C~60 °C/-4 °F~140°F
Chassis Material	Plastic
