Description

Overview

Name: MP-4KHDM-V2
SKU: 3572
Price: 850.00 USD
Availability: InStock

Printed signs are something from the past. Avenview HDMI Digital Signage Player delivers hardware HD video playback for smooth 4K and 1080p video with an advanced onboard processing power for stunning HTML5 content playback. MP-4KHDM-V2 is a plug and play device with no setup required, Plug in power, network and HDMI, and it's ready to play contents on any display. The MP-4KHDM-V2 is fanless, with its specially designed casing and smart ventilation architecture it says cool 24/7. Avenview digital signage player features a built-in self-recovery function (SRF) that keep things running regardless of conditions (sudden reboots or power outage). It includes a micro-SD slot expandable up to 128GB for longer presentations.

The MP-4KHDM-V2 has a unique features which does not lock user to a specific software to create contents, we partnered with the most prominent digital signage content management software developers such as Scala, SignageLive, PosterDigital and much more which are all fully compatible with the MP-4KHDM-V2. So, users are free to use any software they prefer with the MP-4KHDM-V2. The MP-4KHDM-V2 is great for any application from menu boards, hospitality screens, campus signage, and corporate communications. It handles any Full HD application with ease. It’s great for retail applications as well, driving digital posters and other screens.

Features

Always On with App Lock feature to prevent unauthorized access
HTML5 technologies including CSS and Javascript
Widgets for calendar, clock, news, weather, and web page integration with the ability to add custom created widgets
Multi-zone screen layout, transparent PNG overlay, and graphical scrolling ticker
Auto-play starts playing scheduled contents automatically when powered on
Fanless (zero noise) with built-in 16 GB SSD storage
Automatic error recovery with built-in WDT
Real-time clock with backup clock battery
AV SignPRO PC Software to create media content with the ability to use third-party solutions (optional license)
Micro SD card slot (support up to 128GB storage)
Strong Cache for continued playback even when the network is not available
Built-in wall mount bracket
1 year warranty

Specifications

ITEM	DESCRIPTION
UNIT	MP-4KHDM-V2
UNIT DESCRIPTION	4K Digital Signage Player
HDMI STANDARD	HDMI 2.0
PRIVACY AND SECURITY	Password Protected
VIDEO FORMAT SUPPORTED	H.265/HEVC up to 4K (3840x2160), H.264/AVC up to 1080p (1920x1080), MPEG-4 up to 1080p (1920x1080), MPEG-2 up to 1080p (1920x1080), MPEG-1 up to 1080p (1920x1080), VC-1 up to 1080p (1920x1080)
CONNECTIVITY	OSD, Telnet, WebGUI, IR remote and RS-232
AUDIO SUPPORT	Supports LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS 2/5.1CH (Bypass), DolbyTrueHD and DTS-HD Master Audio
CONNECTIVITY	Gigabit Ethernet, Wireless: 802.11 b/g/n (2.4 GHz), HDMI 2.0 (3840x2160 @60fps), Micro USB for ADB, USB 2.0 x 2, 3.5mm analog stereo audio out, AniBeacon™ (BLE), Optional 3G/4G mobile module via USB
AUDIO SUPPORT	Supports LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS 2/5.1CH (Bypass), DolbyTrueHD and DTS-HD Master Audio
CONTENT MANAGEMENT	AVSignPRO Software, 3rd party solution (optional license)
CONTROL	PC Software and OSD
INPUT	1x RJ45, 2x USB 2.0, 1x Micro SD Slot
OUTPUT	1x HDMI, 1x 3.5mm Audio Out
HDMI CONNECTOR	Type A (19 pin female)
LOCAL STORAGE	16 GB eMMC built-in exapandable up to 128 GB with Micro SD Card
POWER ADAPTER	100-240V, 50-60 Hz, 0.5A Max.12V/1.5A DC
POWER CONSUMPTION	7W Max
DIMESNION L X W X H	6.54” x 4.92” x 1.06”
WEIGHT	0.98 lbs
*ENVIRONMENTAL*
OPERATING TEMPERATURE	-4° ~ 122°F (-20° to 50°)
STORAGE TEMPERATURE	-4° ~ 140°F (-20° ~ 60°C)
ESD PROTECTION	Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)
RELATIVE HUMIDITY	20~85% RH (no condensation)
