1×4 DisplayPort with PCM and 2560×1600 Support

1×4 DisplayPort with PCM and 2560×1600 Support

$495.00

Model:  SPLIT-DPDL-4A
Add to Wishlist
Categories: ,

Description

Overview

The Avenview SPLIT-DPDL-4A 4 port splitter has the ability to duplicate a single DP (DisplayPort) source to any four DP screen /display. This unit also has two useful features – supports resolutions up to 2560x1600 and extends PCM 7.1 audio to the supported DP screens/displays attached.
Video Signals: up to 2560x1600
Audio Signals: PCM 7.1
The SPLIT-DPDL-4A includes one unit: 4 Port Splitter with one (1) DisplayPort Input that can and four (4) DisplayPort Outputs.

Features

--CONNECTOR DisplayPort specification
--RESOLUTION: Deep Color video up to 12-bit, resolution support up to 2560x1600
--AUDIO: up to PCM 7.1CH (32-192kHz Fs sample rate)
--PIXEL: Component format with RGB; YCbCr 422; YCbCr 444
--COMPATILBLE VIDEO :Color space conversion between RGB and YCbCr color space
--CABLE RATE: 1.62/2.7 Gbps data rate (Low/High bit rate)
--FEATURE : Flexible 1/2/4 lanes configurations;
--LINK TRANSMISSION: Full 10.8Gbps data rate support (4lanes at 2.7Gbps)
-- SETTINGS: Supports EDID switch and setting
-- COLOR BIT: 24/30/36 bit
-- LINK TRANSMISSION: Up to 10.2Gbps (340MHz)
-- DISTANCE: Up to 15 meters (50ft) w 24AWG DisplayPort Cable

Technical Specifications

ITEM

DESCRIPTION

UNIT

SPLIT-DPDL-4A

UNIT DESCRIPTION

1X4 DP splitter with PCM audio support

DP COMPLIANCE

YES

DPCP

Compliant

VIDEO BANDWIDTH

10.8Gbps (4lanes at 2.7Gbps)

VIDEO SUPPORTED

2560X1600 DEEP COLOR 12BIT
SEE ALSO Section 3

DISPLAY PORTCABLE

WQXGA: (2560X1600) ~ IN 5m(16ft) OUT 10m(33ft)

AUDIO SUPPORT

PCM 7.1(32-192kHz Fs sample rate)

ESD PROTECTION

Human body model — ±8kV (air-gap discharge)
±4kV (contact discharge)

INPUT

1 x DisplayPort Type A (20 pin female)

OUTPUT

2 x DisplayPort Type A (20 pin female)

LED

Front Panel Indicators

DIMENSIONS (L X W X H)

10.6” x 5” x 1.14”
270(W) x 124.5(D) x 29(H)

WEIGHT

1.5 lbs
680g

POWER SUPPLY

5V / 3A DC
(US/EU standards, CE/FCC/UL certified)

POWER CONSUMPTION

7 Watt (max)

ENVIRONMENTAL

OPERATING TEMPERATURE

32? ~ 104?F (0? to 40?C)

STORAGE TEMPERATURE

-4? ~ 140?F (-20? ~ 60?C)

RELATIVE HUMIDITY

20~90% RH (non-condensing)

Package Contents

  • 1 x SPLIT-DPDL-4A
  • 1 x Power Adapter (+5VDC, 3A)
  • 1 x User's Manual

HDMI Extender over CAT5 Application Diagram

User Guides

Avenview 1X4 HDMI 4K2K Splitter with 1080P 3D ULTRA HD User GuideAvenview SPLIT-DPDL-4A User Guide



FAQ Warranty & RMA Product Registration Avenview Tech Support
MICROSITE

Additional information

Weight 0.68 kg
Dimensions 27 × 12.45 × 2.9 cm
