The Avenview SPLIT-HDM2-T4K-4-V2 (4 Ports) HDMI Splitter can support the new industry of video signals 4K@60 and UHD. This device allows the Input (source as 4K GPU graphic card or UHD Digital Player) to be duplicated onto 4 4K@60 or UHD displays. Supporting both video and audio signal simultaneously reproducing the same quality via HDMI cable with EDID management. Video Signals: 4K@60 HDR(4:2:0 10bits) / (4:4:4 8bits), 4K@30, UHD, 3D, Deep Color, and 1080p 24-bit color depth. Audio Signals: DTS-HD Master Audio, Dolby TrueHD Dolby Digital, DTS, DVD-Audio, LPCM, SACD, MPCM The SPLIT-HDM2-T4K-4-V2 includes one unit: 4 ports SPLITTER with one (1) HDMI Input that can extend up to 5m (16ft) and four (4) output ports which allows the user to extend over HDMI cable video and audio up to 5m (16ft) Features | - INPUT: HDMI 2.0 /DVI 1.0 support
- INPUT 4K@60 HDR(4:2:0 10bits) / (4:4:4 8bits), 4K@30, UHD, 3D, Deep Color, and 1080p 24-bit color depth;
- HDCP 2.2 Compliance;
- COLOR SPACE: xvYCC, x.v.Color & Deep Color;
- VIDEO RESOLUTIONS: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz/3D, 1080i@50/60Hz,1080p @ 24Hz /50/60Hz/3D, ULTRA HD (3840x2160)@24/30/60Hz 4K (4096x2160)@24/30/60Hz
- PC RESOLUTIONS: 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x720@60Hz,
- 1280x768@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600x900@60Hz,1680x1050@60Hz, 1920x1080@60Hz 1920x1200@60Hz ULTRA HD (3840x2160)@24/30/60Hz 4K (4096x2160)@24/30/60Hz
- FREQUENCY RANGE: 25MHz~600MHz
- LINK TRANSMISSION: up to 18Gbps (600MHz)
- DISTANCE: up to 5 meters (16ft) w 24AWG High Speed Ethernet HDMI Cable
- EDID: Multi mode selection & EDID learning from Display
- FIRMWARE: Update by mini USB connector
- PLUG & PLAY |
Specifications | Item | Description | UNITS | SPLIT-HDM2-T4K-4-V2 | UNIT DESCRIPTION | ULTRA HD/ 4k@60 SPLITTER | HDCP COMPLIANCE | HDCP 2.2 | VIDEO BANDWIDTH | Single-Link 600MHz (18 Gbps) | HDMI SUPPORTED RESOLUTIONS | HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits) | HDMI CABLE | 5-15meter (50feet) | AUDIO SUPPORT | Dolby TrueHD, Dolby Digital plus and DTS-HD Master Audio Dolby Digital, DTS, DVD-Audio, LPCM, SACD, MPCM | DIP SWITCH | EDID Mode Selection | ESD PROTECTION | Human body model — ±15kV (air-gap discharge) & ±8kV (contact discharge) | INPUT | 1 x HDMI Type A (19 pin female) | OUTPUT | 4 x HDMI Type A | LED | Port Indicators | DIMENSIONS (L X W X H) | 7.8” x 5.4” x 2.9” | WEIGHT | 6 Oz. (170 g) | POWER SUPPLY | 5V / 1A DC , CE/FCC/UL Certified) | POWER CONSUMPTION | 4 Watt (max) |
|
|
