Description

Overview

Avenview C-HDM-COMPVGA-A HDMI down converter with digital and analog audio support was designed to
accept a HDMI signal and convert Full HD along with audio to either VGA+SPDIF/LR sink or YPbPr+SPDIF/LR sink
to a monitor or projector.

Features

Support video input: HDMI;
Toggle switch YPbPr/VGA;
Support audio output: SPDIF (Optical) + R/L analog;
Support output: Support up to PC UXGA and Video1080I (50/60Hz);
HDCP compliant;
LED: Source / Sink working, LED
No loss of quality;
DC5V/1A power supply.

Technical Specification

Model	C-HDM-COMPVGA-A
Description	HDMI / DVI to Component / VGA with Audio Converter
Video Bandwidth	Single Link: 225MHz (5.1Gbps)
Supported Resolutions	Single Link: 1080p 60, WUXGA (1920x1200@60Hz) Component Video: 720p / 1080i
Audio Support	SPDIF(Optical)+R/L Analog
Output Video Signal	1.2 Volts (peak-peak)
Output DDC Signal	5 Volts (peak-peak, TTL)
Input	1 x HDMI
Output	1xVGA
	1xOptical Digital
	1xYPbPr Component Audio
	1xL/R Stereo Audio
VGA Connector Type	HD-15 (15-pin D-sub female)
HDMI Connector	Type A (19 pin female)
RCA Connector	Coaxial S/PDIF Digital Audio (PCM 48kHz)
Dimensions	17.25" x 17.25" x 3.5" (L x W x H)
Power Supply	5V 1A DC
Power Consumption	4 Watts (max)
Operating Temperature	0~40°C [32~104°F]
Storage Temperature	-20~60°C [-4~140°F]
Relative Humidity	20~90% RH [no condensation]
