Overview

The Avenview Modular chasis based 4K Video Wall Processor. This device has brought new changes to the videowall industry with it first ever FPGA design utilizing it functions as it core and embedding industry recognize video processors.

With Avenview being in the videowall market for over 8 years, we developed a very reliable hardware design and stable systen design with the most flexibility on the input and output cards. It is compatible with standard definition (SD), Full HD (1080p), WQXGA (2160x1600) and 4K.

Accepting 4K signal formats with our modular input and output board design with video connectors such as Dual Link DVI, DisplayPort and HDM which offers impeccable quality across multiple screens. The videowall procesor also can mix and match our line of I/O cards which could be installed into the appointed space such as CVBS,YPbPr,VGA,DVI, HDMI, SDI, DisplayPort, twisted pair and optical fiber. These I/O cards offer extremely high video bandwidth , which ensures real-time signal processing, with no delay or frame loss. The unit is equipped with a separate DVI port for real time monitoring with an externaal monitor at 60fps with no frame loss.

No in-dept traing to use our new Control Software, with creative useful features for any client solution such as drag n drop , image placement, zoom, and user preset buttons to recall favorites. Bonus feature our software can also preview the input source directly within the Control Software which is connected through TCP/IP. Enjoy using your touch devices with our optional automation linux based controller to manage multiple videowall and layouts with fully customizable interface. It also supports a 2x2 ,3x3, and 4x4 -16 grid format on a single disply with a click of the mouse.

Having FPGA as its core design this technology enable this unit to manage multiple videowalls with one single processor. The user has the ability to control each video-wall separaetly within the control software. The output resolution can also be managed within each individual screen/monitor and also for different videowalls.

Features

•
• Modular input and output chasis design 720x480 to 4096x2160 with a local DVI loop out for monitoring;
• Supports CVBS,YPbPr,VGA,DVI, HDMI, SDI, DisplayPort,UTP and optical fiber;
• Full screen modes Zoom, image crop and adjustable size & position through software;
• Functions perfectly as a multiviewer, video screen splitter, video converter and matrix switcher;
• Single screen grid formating 2x2,3x3,4x4;
•
• Minimum single screen to 64 screens horizontally /32 screens vertically 600x800, 768x1024, 768x1024, 720x1280,
  800x1280, 1024x1280, 768x1366, 768x1360, 1050x1400, 900x1440, 1200x1600, 1050x1680, 1080x1920, 1200x1920
• Image parameters and layouts are automatically saved in Preset Mode of the device creating easy buttons;
• Background Image storage;
• Management of Multiple Videowalls;
• EDID Management;
• Input Signal preview through Control Software
• Software control throughTCP/IP
• 2/4/8/13U size

Technical Specification

DVI-AVXWALL

Multi-Input Image Video Wall processor with 4K support

CVBS,YPbPr,VGA,DVI, HDMI, SDI, DisplayPort,UTP and optical fiber;

Yes DVI

SD Up to 1080p, 4K (4096x2160@24Hz)

No

TCP/IP

Human body model - ? 15kV (air gap discharge) & ±8kV (contact discharge

4 x CVBS Component-720×576?PAL?720×480?NTSC?

4 x RGBHV/YPbPr- 1920×1200@60Hz

4 x DVI- D digital T.M.D.S signal in DVI 1.0 1920x1200@60Hz

4 x HDMI 1920x1080/1920x1200@60Hz

8 x SDI SMPTE 259M/292M/424M 1920x1080p

2 x Dual -Link DVI 4096x2160@24Hz, 3840x2400@30Hz, 2560x1600@60Hz

2 x Displayport 4096x2160@24Hz, 3840x2400@30Hz, 2560x1600@60Hz

4 x HDBaseT 1920x1080/1920x1200@60Hz

4 x DVI- I 1920×1200@60Hz

4 x HDBaseT 1920x1080/1920x1200@60Hz

2 x Dual -Link DVI 4096x2160@24Hz, 3840x2400@30Hz, 2560x1600@60Hz

2 x HDMI 4096x2160@24Hz, 3840x2400@30Hz, 2560x1600@60Hz

DVI-I (29-Pin female)

WE/SS 8P8C with 2 LED indicators

2U 4 I/O SLOTS 482 x 88 x 380 2380 (L x W x H)

AC 100-240V

150 Watts (max)

0~40°C [32~104°F]

-10~60°C [14~140°F]

20~90% RH [no condensation]

Package Contents
